Description
Safety
● Three braking systems, can provide necessary protection for vehicle and driver.
● OPS system, when drive leaves seat, the forklift will stop working.
Energy saving
● With LED headlight, warning light, low-resistance tyre, automatic steering dormancy, electronic automatic temperature control system and others.
Comfortable
● Reduce impacting and cargo damage with mast battering technology, suspention seat.
● Ergonomic design of cab, provide a comfort, safe and high efficient working environment.
Stable
● Separate vehicle and battery, making gravity is in the center, more stable.
● Curtis controller, Free maintenance full AC system, Imported proportional valve.
MAIN SPECIFICATIONS
Brand |
| UN |
Model |
| TFC30 |
Power Type |
| Battery |
Operation Type |
| Seated |
Service weight (incl. battery) | kg | 5480 |
Rated Capacity | Q(kg) | 3000 |
Load Center | C(mm) | 600 |
Lifting height | h3(mm) | 3000 |
Forks size | l/e/s(mm) | 1200/150/50 |
Front Overhang | x(mm) | 305 |
Turning radius | Wa(mm) | 2000 |
Max. climbing ability | % | 8/10 |
Driving speed(load/unload) | km/h | 7.8/9 |
Lifting speed(load/unload) | mm/s | 170/220 |
Lowering speed(load/unload) | mm/s | 130 |
Specifications and characteristics are subject to change without notice.
